Introduction:
Modern network security has long trusted Protective DNS (PDNS) filtering as a foundational layer to block malicious command-and-control (C2) traffic, malware delivery, and phishing domains. However, a newly weaponized architectural weakness in Content Delivery Networks (CDNs)—dubbed “Underminr”—allows adversaries to completely bypass DNS-based filtering by hiding malicious connections behind trusted, high-reputation domains. This technique forces a device to resolve a permitted domain’s IP address but then connect to that same CDN edge node using the Server Name Indication (SNI) of a different malicious domain on the same shared infrastructure, creating a critical blind spot for defenders.
Learning Objectives:
- Understand the technical mechanics of the Underminr attack and how it differs from traditional domain fronting.
- Master advanced detection methods, including deep packet inspection (DPI) techniques and TLS fingerprinting, to uncover CDN evasion attempts.
- Learn proactive mitigation strategies, from CDN tenant isolation to network-level SNI and HTTP Host header correlation.
You Should Know:
- Technical Deep Dive – From Domain Fronting to Underminr’s Shared IP Abuse
Domain fronting, largely mitigated by major CDNs in 2018, relied on a mismatch between the TLS SNI (visible to inspectors) and the encrypted HTTP Host header (hidden target). Underminr takes a more insidious route: the client performs a legitimate DNS lookup for a trusted domain (e.g., trusted-cdn.com), receives a shared edge IP (e.g., 203.0.113.55), but then establishes a TLS connection to that exact IP using the SNI of a malicious domain (e.g., evil-botnet.net). The CDN routes the request based on the SNI to the attacker’s backend, while all DNS logs and passive DNS systems only record the benign query, leaving the security stack entirely unaware of the malicious connection.
This architectural flaw affects an estimated 88 million domains globally, with infrastructure in the US, UK, and Canada disproportionately vulnerable. No CVE has been assigned because the issue is not a software bug but a fundamental design choice in how CDNs multiplex traffic across shared edge IPs without validating the binding between the DNS resolution domain and the SNI presented in the TLS handshake.
2. Attack Modes Breakdown and Detection Strategies
ADAMnetworks has documented four distinct attack modes, each tailored to evade specific defense layers:
- Simple Mode: The client resolves a trusted domain’s IP via PDNS, then connects directly to that IP using the malicious domain’s SNI. Detection requires correlating DNS answers with subsequent SNI and HTTP Host header values in real-time.
-
Split Mode: A legitimate TLS connection is opened first to pass initial DPI SNI checks. Immediately after, a secondary connection to the same CDN IP is opened with the deceptive SNI. Correlation of connection timestamps and destination IPs can reveal this pattern.
-
ECH Mode: Uses Encrypted Client Hello (ECH) to fully encrypt the SNI, rendering traditional SNI-based DPI completely blind to the true destination, even when the DNS lookup is legitimate.
-
Direct-to-IP Mode: Bypasses DNS entirely by connecting to a known CDN edge IP using a deceptive SNI. No DNS query is ever generated for the hidden domain, leaving zero telemetry for defenders.
Detection commands and tools:
To identify potential Underminr abuse, security teams can deploy Zeek (formerly Bro) to monitor DNS and TLS logs:
Zeek script to flag mismatched DNS vs TLS SNI
event dns_A_reply(c: connection, msg: dns_msg, ans: dns_answer, a: addr) {
Store DNS resolutions in a table
local dns_map: table[bash] of string = table();
dns_map[bash] = ans$query;
}
event ssl_client_hello(c: connection, version: count, record_version: count, possible_versions: vector of count, cipher: count, ciphers: vector of count, compression: count, compressions: vector of count) {
local sni = extract_sni_from_hello(c);
if ( c$id$resp_h in dns_map && dns_map[c$id$resp_h] != sni ) {
NOTICE([$note="Underminr_SNI_Mismatch",
$conn=c,
$msg=fmt("DNS resolved %s but SNI presented %s", dns_map[c$id$resp_h], sni)]);
}
}
For live packet inspection, use `tshark` to extract SNI values and correlate with destination IPs:
Capture TLS SNI and destination IP tshark -i eth0 -Y "tls.handshake.extensions_server_name" -T fields -e ip.dst -e tls.handshake.extensions_server_name Real-time alert on mismatches (requires post-processing) tshark -i eth0 -Y "tls.handshake.extensions_server_name" -T fields -e ip.dst -e tls.handshake.extensions_server_name | while read ip sni; do resolved=$(dig +short -x $ip | sed 's/.$//') if [ "$resolved" != "$sni" ] && [ -n "$resolved" ] && [ -n "$sni" ]; then echo "[!] Potential Underminr: IP $ip resolved to $resolved but SNI is $sni" fi done
- Proactive Hardening: Correlating DNS, SNI, and HTTP Headers
Because Underminr exploits the lack of correlation across network layers, the most effective mitigation is to enforce binding between DNS resolution answers, SNI values, HTTP Host headers, and CDN routing decisions. CDN providers themselves must implement tenant-side validation to prevent cross-tenant abuse. However, enterprise defenders can take immediate action:
- Implement eBPF-based monitoring on Linux hosts to track per-connection DNS-to-SNI correlations:
// eBPF snippet to capture DNS responses and TLS SNI for correlation
SEC("kprobe/tcp_v4_connect")
int trace_tcp_connect(struct pt_regs ctx) {
struct sock sk = (struct sock )PT_REGS_PARM1(ctx);
// Store destination IP and later correlate with TLS SNI from userspace
return 0;
}
- Deploy SNI proxy detection at network egress points. Many open-source tools can be configured to log mismatches:
Using sniproxy in debug mode to log all SNI requests
sniproxy -c /etc/sniproxy.conf -f -D 2>&1 | tee /var/log/sniproxy.log
Query logs for suspicious SNI patterns
grep -E "(sni|host)" /var/log/sniproxy.log | awk '{print $NF}' | sort | uniq -c | sort -nr
- Enforce Encrypted Client Hello (ECH) whitelisting where possible. While ECH protects privacy, it also blinds defenders. Consider blocking ECH connections unless the domain is explicitly trusted and the full TLS handshake can be inspected at the application layer.
-
CDN tenant isolation: For critical assets, migrate from shared edge IPs to dedicated IPs or isolated edge capacity provided by CDN vendors. This eliminates the shared IP vector entirely.
-
HTTP Host header validation: Configure reverse proxies and firewalls to reject any request where the HTTP Host header does not match the SNI value:
NGINX configuration to reject mismatched Host and SNI
server {
listen 443 ssl;
server_name trusted-domain.com;
if ($http_host != $ssl_server_name) {
return 403;
}
Normal configuration continues...
}
4. Windows-Specific Detection and Hardening
Enterprise Windows environments can leverage built-in tools and PowerShell to monitor for Underminr-like activity:
Enable DNS client logging to capture all resolution attempts
Set-NetEventSession -Name "DNSSession" -CaptureMode SaveToFile -LocalFilePath "C:\Logs\DNS.etl"
Add-NetEventNetworkAdapter -Name "DNSSession"
Add-NetEventPacketCaptureProvider -Name "DNSSession" -TruncationLength 128
Start-NetEventSession -Name "DNSSession"
Monitor Schannel events for TLS SNI mismatches (Event ID 36880)
Get-WinEvent -FilterHashtable @{LogName='Microsoft-Windows-Schannel/Analytic'; ID=36880} |
Where-Object { $_.Message -match "server name indication" } |
Format-Table TimeCreated, Message -AutoSize
Use Sysmon to log DNS queries and correlate with network connections
Configure Sysmon config with additional DNS logging:
<EventFiltering>
<DnsQuery onmatch="include">
<QueryName condition="contains">.com</QueryName>
</DnsQuery>
</EventFiltering>
sysmon -accepteula -i sysmonconfig.xml
Windows firewall rules to restrict outbound TLS connections based on SNI require third-party tools (e.g., windivert-based proxies), but a simple network policy can block connections to IP ranges known to host shared CDN edge nodes unless the SNI matches an allowed domain list:
Block all outbound traffic to CDN IP ranges except when SNI matches approved domains This requires advanced firewall with L7 inspection like Windows Defender Firewall with Advanced Security + IPSec New-NetFirewallRule -DisplayName "Block Underminr CDN Abuse" -Direction Outbound -RemoteAddress 203.0.113.0/24 -Action Block
5. AI and the Future of Evasion-as-a-Service
The most concerning projection from ADAMnetworks is that once Underminr becomes parametric information for AI-generated malware, we can expect it to be embedded in virtually every attack that requires evading protective DNS. Adversarial AI can automate the discovery of co-hosted domains on shared CDN edges, generate thousands of polymorphic SNI values, and dynamically rotate malicious domains without ever triggering a DNS-based alert. Defenders must therefore shift from reactive signature-based detection to behavioral and correlational analytics, leveraging machine learning models trained on normal CDN routing patterns to flag anomalies.
Sample Python script to test if a domain is vulnerable to Underminr abuse:
import socket
import ssl
import dns.resolver
def test_underminr_vulnerability(trusted_domain, malicious_domain, cdn_edge_ip=None):
Resolve trusted domain to get CDN edge IP
if not cdn_edge_ip:
answers = dns.resolver.resolve(trusted_domain, 'A')
cdn_edge_ip = str(answers[bash])
Attempt direct-to-IP connection with malicious SNI
context = ssl.create_default_context()
with socket.create_connection((cdn_edge_ip, 443), timeout=5) as sock:
with context.wrap_socket(sock, server_hostname=malicious_domain) as ssock:
ssock.do_handshake()
cert = ssock.getpeercert()
If the certificate matches the malicious domain, the CDN is vulnerable
if cert['subjectAltName'][bash][1] == malicious_domain:
return True
return False
Example
vulnerable = test_underminr_vulnerability('trusted-cdn.com', 'evil-botnet.net')
print(f"Vulnerable to Underminr: {vulnerable}")
What Undercode Say:
- Key Takeaway 1: DNS filtering alone is no longer sufficient; organizations must implement multi-layer correlation of DNS answers, TLS SNI fields, and HTTP Host headers to detect Underminr-style evasion.
- Key Takeaway 2: CDN providers bear the ultimate responsibility for fixing this architectural flaw through tenant-side validation and dedicated IP offerings, but immediate enterprise countermeasures—including eBPF monitoring, SNI whitelisting, and ECH controls—can significantly reduce risk.
Analysis: The Underminr technique represents a paradigm shift in network evasion: it weaponizes the very infrastructure designed to optimize web performance. Unlike traditional domain fronting, which required a mismatch between SNI and Host header, Underminr leverages a legitimate, allowed DNS resolution to a shared edge IP, then simply presents a different SNI during the TLS handshake. This bypasses all DNS-level security controls because the initial resolution is clean. The attack is already actively exploited, and with AI-orchestrated malware on the horizon, the window for proactive defense is closing. Security teams must treat this not as a theoretical vulnerability but as an active threat requiring immediate architectural review.
Prediction:
Underminr will force a fundamental rearchitecture of how CDNs and security tools interact. By Q4 2026, we will see the emergence of “federated DNS-TLS correlation standards” enforced at the protocol level, likely as an extension to TLS 1.4 or a new IETF working group. In the near term, expect a surge in demand for dedicated CDN edge IPs and zero-trust network access (ZTNA) solutions that completely bypass traditional DNS filtering. Adversaries will pair Underminr with AI-generated domain registration, leading to “evasion-as-a-service” offerings on cybercriminal forums. Organizations that fail to adopt correlational detection will face undetected C2 channels, stealthy data exfiltration, and a false sense of security from their DNS filtering investments.
