Introduction:
Operational Technology (OT) and Industrial Control Systems (ICS) face unique risk landscapes where safety and availability trump confidentiality. The NCSC-1L’s “Leerlijn Risicomanagement” (Risk Management Learning Path) provides a structured approach to identifying, assessing, and mitigating cyber-physical threats—blending traditional IT risk frameworks with industrial-specific consequences like production downtime or equipment damage. This article extracts actionable techniques from the event’s parallel sessions, delivering hands-on commands, configuration hardening steps, and risk assessment templates for both Linux-based ICS gateways and Windows engineering workstations.
Learning Objectives:
– Apply NCSC-1L’s risk assessment methodology to an ICS environment using asset inventory and threat modeling.
– Harden Linux-based PLC programming workstations and Windows SCADA servers with verified security baselines.
– Implement network segmentation and monitoring rules for Modbus/TCP and S7 protocols using open-source tools.
You Should Know:
1. Asset Discovery & Risk Scoring for ICS Environments
Start by identifying all OT assets—PLCs, RTUs, HMIs, engineering workstations—and mapping them to business processes. Use the NCSC-1L “Beoordeling” (assessment) matrix to assign risk scores based on likelihood of compromise and impact on safety or production.
Step‑by‑step guide:
– On Linux (Kali or Ubuntu with nmap): Scan a PLC subnet (e.g., 192.168.1.0/24) for Modbus/TCP devices (port 502) and S7 communication (port 102).
sudo nmap -sS -p 502,102 --open -T4 192.168.1.0/24 -oG ics_scan.gnmap
grep "502/open" ics_scan.gnmap | awk '{print $2}' > modbus_hosts.txt
– On Windows (PowerShell with Test-1etConnection): Enumerate engineering workstations with open RDP (3389) or WinRM (5985) that could be pivoting points.
foreach ($ip in (Get-Content -Path ".\target_ips.txt")) {
Test-1etConnection -Port 3389 -ComputerName $ip -InformationLevel Quiet | Out-File -Append .\rdp_check.txt
}
– Risk scoring template (CSV): Create a table with columns: `Asset_IP`, `Protocol`, `Criticality (1-5)`, `Likelihood (1-5)`, `Risk_Score`. Calculate as `Criticality Likelihood`. Prioritize scores ≥ 12.
2. Hardening Siemens S7-1200/1500 PLCs with NCSC-1L Baselines
NCSC-1L recommends disabling unnecessary protocols, enabling logging, and using secure engineering access. Many parallel sessions highlighted that default S7 communication lacks authentication—mitigate via access control lists (ACLs) on the PLC itself or a gateway firewall.
Step‑by‑step guide:
– Configure ACL on a Linux-based industrial firewall (e.g., Raspberry Pi running iptables): Allow only specific engineering workstation IPs (e.g., 10.0.0.50) to access PLCs on port 102.
sudo iptables -A INPUT -p tcp --dport 102 -s 10.0.0.50 -j ACCEPT sudo iptables -A INPUT -p tcp --dport 102 -j DROP sudo iptables-save > /etc/iptables/rules.v4
– On Windows (engineering station): Disable unused network services that could be exploited to reach the PLC. Run PowerShell as Admin:
Get-Service -1ame "RemoteRegistry","Telnet","SSH Server" | Stop-Service -Force Set-Service -1ame "RemoteRegistry","Telnet","SSH Server" -StartupType Disabled
– Tutorial – PLC password hardening: In TIA Portal, set a strong password (≥12 characters, mixed case, symbols) for the PLC’s “Know-how protection” and also enable “Firmware protection” to prevent downgrade attacks.
3. Network Segmentation Using VLANs and Industrial Firewalls
The event’s “Leerlijn Risicomanagement” stressed zone‑and‑conduit models as per IEC 62443. Separate OT, DMZ, and enterprise IT networks. Use open‑source pfSense or commercial hardware to enforce rules.
Step‑by‑step guide:
– On pfSense (Linux/FreeBSD): Create VLAN for OT (e.g., VLAN 10, subnet 10.10.10.0/24) and another for engineering (VLAN 20, 10.20.20.0/24). Block all traffic from OT to enterprise except specific Modbus responses.
pfSense shell commands to add VLAN and firewall rules (conceptual) ifconfig vlan10 create vlan 10 vlanparent em0 inet 10.10.10.1/24 netmask 255.255.255.0 pfctl -a 'ot_zone' -f /etc/pf.conf.d/ot_rules
Sample pf rule in /etc/pf.conf.d/ot_rules:
block in on vlan10 from any to 192.168.0.0/16 pass in on vlan10 proto tcp from 10.10.10.0/24 to 10.20.20.100 port 502 allow Modbus reads
– On Windows Server (ICS Historian): Configure Windows Firewall to allow only specific SCADA IPs. Open `wf.msc` → Inbound Rules → New Rule → Custom → Protocol TCP, local port 1433 (SQL) or port 80 (HMI web) → scope: remote IP addresses of allowed engineering consoles.
– Verification: Use `nmap` from an unauthorized host to confirm ports 502/102 are filtered. Example:
nmap -p 502 --max-retries 1 10.10.10.2 should show filtered or closed
4. Monitoring Modbus/TCP Anomalies with Zeek (Bro)
Zeek (formerly Bro) can detect function code anomalies, unit ID scanning, and excessive coils reads that indicate reconnaissance or attacks. NCSC-1L sessions recommended Zeek as a lightweight ICS IDS.
Step‑by‑step guide:
– Install Zeek on Ubuntu:
sudo apt update && sudo apt install zeek -y sudo ln -s /opt/zeek/bin/zeek /usr/local/bin/zeek
– Enable Modbus analyzer: Edit `/opt/zeek/share/zeek/site/local.zeek` and add:
@load protocols/modbus
– Start monitoring interface (e.g., eth1 mirroring the OT switch port):
sudo zeek -i eth1 -C -v /opt/zeek/share/zeek/site/local.zeek
– Analyze logs: Check `modbus.log` for unusual read/write counts or function code 90 (illegal function). Example to alert on function code 90:
cat modbus.log | zeek-cut func | sort | uniq -c
– Windows alternative: Use Wireshark’s TShark with custom display filters:
& 'C:\Program Files\Wireshark\tshark.exe' -i "Ethernet1" -f "tcp port 502" -Y "modbus.func_code == 90" -T fields -e ip.src -e modbus.unit_id
5. Mitigating ARP Spoofing in Flat ICS Networks
Many legacy ICS networks operate flat Layer 2, making them vulnerable to ARP poisoning (e.g., intercepting SCADA-to-PLC traffic). Use dynamic ARP inspection (DAI) on managed switches or static ARP entries on critical hosts.
Step‑by‑step guide:
– On Linux (SCADA gateway): Set static ARP for all PLCs (IP to MAC) to prevent spoofing. First, obtain MAC addresses:
arp -1 | grep 10.10.10. assume PLC subnet
Then create static entries (replace with actual IP/MAC):
sudo arp -s 10.10.10.2 00:11:22:33:44:55 sudo arp -s 10.10.10.3 aa:bb:cc:dd:ee:ff
– On Windows HMI: Use `netsh` to add static neighbors:
netsh interface ipv4 add neighbors "Ethernet0" "10.10.10.2" "00-11-22-33-44-55"
– Switch configuration (Cisco IOS-like): Enable port security and DAI on VLAN 10:
ip arp inspection vlan 10 interface GigabitEthernet1/0/1 switchport port-security maximum 1 switchport port-security mac-address sticky
– Verification: Test by running an ARP spoofing tool (e.g., `arpspoof` from `dsniff`). If static entries are used, the attack will fail and you’ll see “ARP reply ignored” in logs.
What Undercode Say:
– Risk management in OT is not just IT risk transposed – NCSC-1L’s learning path emphasizes consequence-driven prioritization (loss of life/environment) over data confidentiality.
– Practical automation bridges the gap – using open-source tools like Zeek and iptables allows resource‑constrained teams to implement IEC 62443 controls without expensive commercial solutions.
Analysis: The event highlighted that parallel sessions often contradict each other (e.g., “patch everything” vs. “never patch without vendor approval”). The most valuable takeaway is the “risk register” approach where each asset’s required availability is documented. For example, a safety PLC should have risk mitigation like redundant network paths and read‑only monitoring, while a non‑critical HMI can tolerate periodic patching. The absence of vendor‑agnostic commands in many trainings is a gap—this article fills that with concrete Linux/Windows steps. Also, note that NCSC-1L’s “Leerlijn” advises performing tabletop exercises using the documented risk scores; a simple bash script can generate random incident scenarios from the risk register.
Prediction:
– -1 Over the next 18 months, more OT breaches will originate from engineering workstations that bypass network segmentation via dual-homed connections—NCSC-1L will likely release a “Securing Remote Engineering Access” addendum.
– +1 Adoption of lightweight, open‑source IDS like Zeek for Modbus/DNP3 will increase by 60% in mid‑sized manufacturing, driven by the Leerlijn Risicomanagement’s free templates.
– -1 Legacy PLCs (pre-2010) running unauthenticated S7Comm will remain a dominant risk vector as organizations struggle to justify replacement costs; expect state‑aligned groups to weaponize known CVEs (e.g., CVE-2016-9152) in targeted attacks.
– +1 The NCSC-1L’s community event will catalyze a European‑wide ICS risk management certification based on the Leerlijn curriculum, standardizing assessment methods across critical infrastructure.
