Introduction:
The convergence of Information Technology (IT) and Operational Technology (OT) has created a critical skills gap: understanding how to defend industrial processes rather than just data. Moving beyond theoretical certifications like CCNA and Security+ requires a shift in mindset from “Confidentiality” to “Availability.” This article leverages the practical frameworks found in Pascal Ackerman’s Industrial Cybersecurity to provide a hands-on roadmap for setting up a home lab, simulating attacks on ICS protocols, and implementing risk-based hardening techniques for industrial environments.
Learning Objectives:
- Understand how to map industrial assets (like Siemens PLCs) to the Purdue Model for network segmentation.
- Configure and deploy a honeypot (Conpot) to capture live ICS protocol attacks (Modbus, S7Comm).
- Implement risk-based hardening strategies that prioritize availability over immediate patching.
- Perform basic traffic analysis and exploitation of industrial protocols using common CLI tools.
- Deconstructing the Purdue Model with Network Segmentation (Linux & Simulation)
The Purdue Model is the backbone of OT security, separating corporate IT from the dirty floor of the ICS. To visualize this, you need to simulate network segmentation.
Step‑by‑Step Guide:
- Simulate the Levels: Using a hypervisor (like VirtualBox/VMware), create three virtual networks.
– Level 3 (Site Operations): A Linux machine acting as the Historian/Asset Server.
– Level 2 (Supervisory): A machine running OpenPLC or a simulator for a Siemens S7-1500 (using tools like Snap7).
– Level 1 (Basic Control): A separate VM acting as a simple controller.
- Implement the Firewall (iptables on Linux): On the Linux machine acting as the router/firewall between Level 3 and Level 2, enforce strict segmentation.
Allow Level 3 to initiate connections to Level 2 for monitoring (e.g., Modbus TCP port 502) sudo iptables -A FORWARD -i eth3 -o eth2 -p tcp --dport 502 -m state --state NEW,ESTABLISHED -j ACCEPT sudo iptables -A FORWARD -i eth2 -o eth3 -p tcp --sport 502 -m state --state ESTABLISHED -j ACCEPT Block Level 2 from initiating connections back to Level 3 (preventing lateral movement) sudo iptables -A FORWARD -i eth2 -o eth3 -j DROP Log dropped packets for intrusion detection analysis sudo iptables -A FORWARD -i eth2 -o eth3 -j LOG --log-prefix "PURDUE_DROP: "
What this does: It simulates a DMZ-like environment where the corporate network can pull data from the control network, but a compromised device on the control network cannot “phone home” or attack corporate assets.
-
Deploying an ICS Honeypot (Conpot) to Catch Attackers
Conpot is a low-interaction honeypot that simulates industrial systems. Using insights from Ackerman’s book, we configure it to mimic a Siemens S7-300 to lure attackers.
Step‑by‑Step Guide (Linux):
1. Installation:
sudo apt-get update sudo apt-get install git python3 python3-pip git clone https://github.com/mushorg/conpot.git cd conpot sudo pip3 install -r requirements.txt sudo python3 setup.py install
- Customize the Template: Modify the configuration to mimic a Siemens environment.
Copy the default config cp conpot/default.cfg /etc/conpot/conpot.cfg Edit the template to use the Siemens S7-200 slave Look for the protocol section and ensure "s7comm" is enabled
Note: In the configuration file, you can change the IP address and MAC address to blend into your lab environment.
3. Run and Monitor:
sudo conpot --template default
On a separate attack VM (Kali Linux): Simulate a scan.
Use Nmap to scan for Siemens PLCs (S7Comm usually on port 102) nmap -sV -p 102 --script s7-info <Honeypot_IP>
Result: The honeypot will log the entire interaction, showing you exactly what commands an attacker tries to send, specifically targeting the S7Comm protocol used by Siemens devices.
3. Risk-Based Hardening: Snapshot vs. Patch (Windows/Linux)
In IT, you patch immediately. In OT, you test. Here is a workflow for “Virtual Patching” by isolating the asset and monitoring behavior.
Step‑by‑Step Guide (Windows Server/Historian):
- Baseline Network Behavior: Before patching an industrial HMI/Historian, capture a baseline of its “normal” traffic.
On Windows, start a packet capture using netsh or download Wireshark. Using netsh for a lightweight capture: netsh trace start provider=Microsoft-Windows-NDIS-PacketCapture capture=yes maxsize=500 filemode=circular tracefile=C:\capture\baseline.etl Let it run for 24 hours during a production cycle. netsh trace stop
-
Hardening via ACL (Linux Gateway): If a vulnerability (like CVE-2021-44228) hits a Java-based HMI, you cannot always patch it. Create a Suricata rule on the OT gateway to block the exploit traffic without taking the box offline.
– Edit /etc/suricata/rules/local.rules:
alert tcp any any -> any 8080 (msg:"Possible Log4Shell Exploit in OT"; content:"${jndi:ldap:"; nocase; sid:1000001; rev:1;)
– Configure Suricata to act in IPS mode (NFQUEUE) and drop the packets.
sudo suricata -c /etc/suricata/suricata.yaml -q 0
What this does: It acts as a virtual patch, buying the OT team time to schedule a maintenance window for the actual update.
4. Analyzing Modbus/TCP Traffic (Command Line)
Modbus is the lingua franca of OT. Learning to dissect it via CLI helps in scripting incident response.
Step‑by‑Step Guide (Linux):
Assuming you have a PCAP file (modbus_attack.pcap) from your honeypot or lab:
1. Extract specific function codes: Attackers often use Function Code 90 (0x5a) for diagnostic or malicious reconfiguration.
Use tcpdump to read the pcap and filter for Modbus traffic tcpdump -r modbus_attack.pcap -vvv -X 'tcp port 502'
- Use tshark (Wireshark CLI) to isolate specific function codes:
Display only Modbus packets with Function Code 16 (Write Multiple Registers) tshark -r modbus_attack.pcap -Y "modbus.func_code == 16" -V
Analysis: By looking at the “Reference Number” and “Data” fields, you can see exactly what memory address the attacker tried to overwrite (e.g., turning off a pump).
5. Reconnaissance and Exploitation Simulation (Kali Linux)
Understanding the attacker’s view helps in hardening. Use standard tools to interact with your simulated Siemens S7-1500.
Step‑by‑Step Guide (Kali):
- Scan for Siemens PLCs: Use `nmap` with the S7Comm script.
nmap -p 102 --script s7-info 192.168.1.100
Output: This reveals the Module (e.g., “S7-300”), the Plant Identification, and serial number—critical info for a targeted attack.
-
Snap7 Client Example: Use the Snap7 Python library to attempt to stop the PLC (simulate a DoS).
!/usr/bin/env python3 import snap7 plc = snap7.client.Client() plc.connect('192.168.1.100', 0, 1) Attempt to stop the PLC (usually requires privilege, but for testing visibility) plc.plc_stop() print("PLC Stop command sent. Monitor physical output.")Defensive Note: Your IDS (like Zeek/SecurityOnion) should alarm on the S7Comm `stop_plc` service call.
6. OT Asset Discovery via GRASSMARLIN (Windows)
The book emphasizes passive mapping. The Department of Homeland Security released GRASSMARLIN for this purpose.
Step‑by‑Step Guide (Windows):
- Capture Network Traffic: On a SPAN port or hub, use Wireshark to record traffic crossing the OT network for 10 minutes.
2. Import into GRASSMARLIN:
- Open GRASSMARLIN.
- Click “New Project” and import the `.pcap` file.
- Navigate the generated map. It will automatically group assets (IP addresses) into Purdue levels based on their communication patterns.
- Result: You will visually see which HMI talks to which PLC. If you see a PLC talking to an external IP via HTTP, you have found a compliance violation.
What Undercode Say:
- Key Takeaway 1: OT Security is not about preventing every exploit; it is about maintaining visibility and availability. The honeypot method (Conpot) and passive mapping (GRASSMARLIN) show you the unseen traffic, which is 90% of the battle.
- Key Takeaway 2: Standard IT tools are insufficient for ICS. You must understand industrial protocols (S7Comm, Modbus) at the packet level to differentiate between a maintenance worker and a threat actor. The `tshark` and `iptables` examples above bridge the gap between “packets” and “physical processes.”
Prediction:
As AI-driven attacks become more sophisticated, the next wave of OT breaches will not target the PLC logic directly, but the Engineering Workstations used to program them. Future defenses will pivot towards “Zero Trust for Engineering,” requiring MFA and session recording for any human-to-PLC interaction, moving beyond the current model of network segmentation into strict identity-based control of physical processes.
